MH200

speaker

หุ่นยนต์หยิบจับ | MH200

Category : Robotic

รายละเอียด
The MH200 is a 6-axis robot specifically designed for materials handling applications, delivering high performance, strength and stability.

Its cables and media supply are integrated in the robot arm, which increases the cable durability, reduces teaching time and potential interference with peripheral equipment. The MH200 has a compact and slim design allowing it to reach into confined spaces and reduce cycle time, thus improving system productivity.
รายละเอียดเพิ่มเติม

Technical Data

Controlled axes 6
Payload 200 kg
Maximum reach P-point 2651 mm
Repeatability ±0.2 mm
Weight 1130 kg
Power requirements 5.0 kVA
Mounting positions Floor
Suitable for Machine tending
  Material handling
  Palletising
  Press Brake tending
  Processing

Maximum speed

S-axis 110º/sec
L-axis 110º/sec
U-axis 110º/sec
R-axis 175º/sec
B-axis 150º/sec
T-axis 240º/sec
