| VKBS CNC V-Cutting Machine
Category : Cutting Machine
รายละเอียด
รายละเอียดเพิ่มเติม
Technical Parameter
Model
|
VKBS-3212 |
VKBS-4012 |
VKBS-6012 |
The company is located in : | ||
Processing performance machining
capacity |
Material plate |
Material |
STS304 & Q235 |
|||
Length |
3200 mm |
4000 mm |
6000 mm |
The company is located in : |
||
Width |
1220 mm |
|||||
Thickness |
0.6 mm-4 mm (Sheet flatness < 3 mm) |
|||||
Minimum edge |
8 mm |
|||||
System configuration CNC
specifics |
Control type |
3-axis CNC control (Y1, Y2, Z) |
||||
Display |
10-inch high-definition LCD color screen |
|||||
Memory capacity |
20 groups, 112 / group (plus SD card expansion) |
|||||
Transmission system |
Ball screw / Linear guide / Rack and pinion |
|||||
Machining speed |
Beam (x-axis) forward cutting |
50 m / min (adjustable frequency) |
||||
Beam (x-axis) backward cutting |
55 m / min |
|||||
Tool holder (Y1 axis) and end pressure material (Y2
axis) |
20 m / min |
|||||
Tool post (z-axis) up and down z-axis up-down |
20 m / min |
|||||
Precision machining
precision |
Tool holder (Y1 axis) minimum resolution Y1 precision |
0.001 mm |
||||
Tool holder (Y1 axis) maximum distrance Y1 stoke |
1250 mm |
|||||
Tool holder up and down (z axis) minimum resolution
Y1 precision |
0.001 mm |
|||||
Tool holder up and down (z axis)
maximum resolution Z precision |
50 mm |
|||||
Driving mode |
Beam (x-axis) |
5.5 Kw frequency conversion motor
SEW |
||||
 |
 |
